Description
System
High-end quality drivers
Tweeter: 1,1″ DAD™ Arrow Point extended frequency neodymium tweeter, Copper shorting ring
Midrange: 1x 4″ Camelia midrange, Copper shorting ring
Woofer: 2 x 6,5″ woofers, Aluminum demodulation ring
Crossover Points
350 Hz – 4000 Hz
Frequency response
45 Hz – 40.000 Hz
Sensitivity
88 dB SPL (2.83 V/1m)
Nominal impedance
4 Ohm
Recommended power amplifier
50 W – 300 W
Decoupling Systems
3,0 way
Midrange sealed enclosure
Woofers rear vented box
Product dimensions (HxWxD)
235 – 648 – 353 mm
9.25 – 25.51 – 13.9 in
Dimensions with packaging (HxWxD)
350 – 755 – 455 mm
13.78 – 29.72 – 17.91 in
Weight
17,63 kg
38.87 lb
