Description
System
2,0 way
Midwoofer front vented box
Loudspeakers
High-end quality drivers
Tweeter: 1,1″ DAD™ Arrow Point extended frequency tweeter, Copper shorting ring
Midwoofer: 1x 5″ Midwoofer, Aluminum demodulation ring
Crossover Points
2100 Hz
Frequency response
52 Hz – 40.000 Hz
Sensitivity
86 dB SPL (2.83 V/1m)
Nominal impedance
4 Ohm
Recommended power amplifier
30 W – 150 W
Product dimensions (HxWxD)
377 – 200 – 304 mm / each
14.8 – 7.87 – 11.97 in / each
687 – 355 – 406 mm (stand dimensions)
27.1 – 13.2 – 16 in (stand dimensions)
Dimensions with packaging (HxWxD)
500 – 555 – 405 mm
19,69 – 21,85 – 15,94 in
831 – 437 – 615 mm (stand)
32.72 – 17.20 – 24.21 in (stand)
Weight
8,4 kg / each
18.52 lb / each
6,50 kg (stand weight)
14.33 lb (stand weight)
Packaging weight
20 kg /one carton inlcudes 2 speakers
44.1 lb / one carton inlcudes 2 speakers
12 kg (stand)
26.46 lb (stand)
Cabinet
Lute shape
Wood
Leather
Concrete
Aluminum – Concrete – Iron Steel (stand)
