Description

Technical Specifications:
System Type
2 ½ way, downwards firing port,

with BassTraxTMTractrix diffuser.

Twin cavity coupled reflex

Recommended amplifier power (Watt RMS) 35-150
Continuous power handling (Watt RMS) 75
Sensitivity (2.83 Volt @ 1m) 90dB
Nominal impedance 8 Ohm
Frequency response (-6dB typical in room) 36Hz-34kHz
Drive unit complement
1 x 150mm IsoFlareTM,

multi-fibre bass/mid with 25mm titanium

dome compression tweeter,

1 x 150mm multi-fibre bass

Crossover frequency 250Hz & 1.7kHz
Crossover type 2nd order low pass, 1st order high pass
Dimensions – HxWxD 984 x 270 x 318mm (38.7 x 10.6 x 12.5”)
Weight – Each 18.9kg (41.7lb)
Finish
Dark Oak
