Description

Specifications
Size & weight
Dimensions
Height: 1218mm (48 in)
Width: 413mm (16.3 in)
Depth: 602mm (23.7 in)
Net weight
88.10kg (194.2 lb)
Technical details
Technical features
Diamond tweeter
Solid body Tweeter-on-Top
Continuum™ cone FST
Anti-Resonance plug
Biomimetic Suspension
Turbine™ Head
Matrix™
Aerofoil™ cone bass units
Flowport
Description
3-way vented-box system
Drive units
1x ø25mm (1in) Diamond dome high-frequency
1x ø150mm (6in) Continuum cone FST midrange
2x ø200mm (8in) Aerofoil cone bass units
Frequency range
14Hz to 35kHz
Frequency response
17Hz to 28kHz (+/-3dB from reference axis)
Sensitivity
90dB (on axis at 2.83Vrms at 1m)
Harmonic distortion
2nd and 3rd harmonics (90dB,1m on axis)
<1% 70Hz – 20kHz <0.3% 100Hz – 20kHz Nominal impedance 8Ω (minimum 3.0Ω) Recommended amplifier power 50W – 500W into 8Ω on unclipped programme Max recommended cable impedance 0.1Ω
