Description

Key Technical Specifications Design:

2-way bass reflexTweeter: 35mm composite Teteron dome in custom waveguide

Woofers: (2) 215mm (8″) Carbon fiber diaphragms

Frequency Response: 31Hz – 27kHz (-6dB); 33Hz – 27kHz (-6dB)Typical

In-Room Bass Extension: 26Hz (-6dB), 17Hz (-10dB)

Sensitivity: 87.7dB – 88.4dB / 2.83V / 1.0m

Impedance: 4\(\Omega \) Nominal / 3.0\(\Omega \)

MinimumRecommended Amplifier Power: 50 – 300WSPL Capability: 112.5dB – 113.2dB peak

Dimensions: 1285H x 280W x 390D mm (\(50.6″\times 11.0″\times 15.4″\))
