Description

GENERAL SPECIFICATIONS LINE INPUT/SPEAKER OUT
Continuous output power into 4 and 8 Ohms60W (ref. 20Hz-20kHz at 0.03% THD, both channels driven)THD (20Hz – 20kHz)<0.005% (at 1W, 4 and 8 ohms)Signal-to-Noise Ratio>98dB (A-weighted, 500mV input, ref. 2.828V out in 4 Ohms)Clipping power>80W (at 1kHz 4 Ohms 0.1% THD)IHF dynamic power8 Ohms : 80W
4 Ohms : 150W
2 Ohms : 200WPeak output current>18A (in 1 Ohm, 1ms)Damping factor>300 (ref. 8 Ohms, 20Hz to 6.5kHz)Frequency response±0.3dB (20Hz – 20kHz)Channel separation>75dB (1kHz)
>70dB (10kHz)Input sensitivity260mV (for 30W in 4 Ohms)Supports bit rate/sample rateup to 24 bit/192kHz (digital source)
up to 24 bit/384kHz (computer source)Standby power<0.5W DIMENSION
