Description

Technical Specifications
System Format: 3-way — 4 driver system
Frequency Response: 28 Hz – 100 kHz (-6 dB)
Sensitivity: 90 dB (1W@1m)
Maximum SPL: 117.8 dBA (pair)
Nominal Impedance: 4 ohms (4.2 ohms minimum @ 111 Hz)
Power Handling (RMS): 300 W
Recommended Amplifier Requirements: 100 – 300 W
Crossover Frequencies: LF/MF: 500 Hz, MF/HF: 3.4 kHz
Design & Dimensions
Cabinet Design: Dual HiVe II reflex ports and sealed midrange TLE
(Tapered Line Enclosure) housing
Dimensions (including feet & spikes): 1111.7 x 432.4 x 517.83 mm (433/4 x 17 x 203/8 inches)Weight: 54.52 kg
