Description

Type Stereo pre-main amplifier
Rated Output (20 Hz to 20 kHz, Both Channel Drive) 70W + 70W (4 Ω)
60W + 60W (6 Ω)
50W + 50W (8 Ω)
Total harmonic distortion factor (20 Hz to 20 kHz, both channel drives) 0.01% (at 8 Ω load)
Intermodulation Distortion Factor (SMPTE) 0.01%
Output Bandwidth (8 ohm load, 0.04%) 10 Hz to 50 kHz
Frequency Response (CD, Source Direct) 5 Hz ~ 60 kHz + 0 -1dB
Damping factor (20 Hz to 20 kHz) 100 or More (8 Ω Load)
Input Sensitivity / Impedance Phono MM : 2.3mV/47k Ω
High Level : 200mV/15k Ω
Signal-to-noise ratio (IHF A network, input short) Phono MM:85dB
High Level:110dB
Tone control Bass : ± 8 dB (100 Hz)
Treble : ± 8 dB (10 kHz)
Power supply voltage 100 VAC, 50Hz/60Hz
Power consumption (Electrical Appliance and Material Control Law) 135W
Maximum external dimensions Width 440x Height 124x Depth 340 mm
Weight 7.5kg
Attachment System remote control
AC Cable
