Description

Core Specifications
Power Output: 300Wpc into 8Ω, 600Wpc into 4Ω, and 950Wpc into 2Ω.
Frequency Response: 0.1 Hz to 350 kHz (–3dB).
Distortion (THD+N): < 0.1%.Output Impedance: 0.019 Ω for high speaker control. Gain: +38dB. Design & CircuitryTopology: True Dual Mono, zero negative feedback. Class A operation: Operates in Class A mode for the first ~10 Watts. Power Supply: Massive dual Holmgren toroidal transformers with 136,000 μF total capacitance. Volume Control: Microprocessor-controlled 43-step fully balanced relay volume attenuator (uses only two resistors at any level). Connections Inputs: 2 x balanced XLR, 3 x unbalanced RCA. Outputs: 1 x Tape out (RCA), 1 x Subwoofer out (+12dB gain). Display: Vacuum-fluorescent touch display with adjustable brightness. Physical Dimensions: 48 W × 23.5 H × 46 D cms. Weight: 38.1 kg
