Description

SPECIFICATIONS

Quantity Included Pair
Orientation Vertical
Height 11.71″ (29.74 cm)
Width 6.5″ (16.51 cm)
Depth 11.97″ (30.4 cm)
Driver Enclosure Type MDF cabinet with extruded natural bead-blasted aluminum front baffle
Driver Complement 5.25″ (13.34 cm) d (Round) Polypropylene BDSS Bass – Mid/Woofer
1″ (2.54 cm) d (Round) Annealed Aluminum Dome and Laterally Offset – Tweeter
5″ (12.7 cm) h x 9″ (22.86 cm) w (Oval) Passive – Bass Radiator
Total Frequency Response 48 Hz → 24,000 Hz
Nominal Impedance 4 ohms
Sensitivity (1 watt @ 1 meter) 88 dB
Lower and Upper -3dB Limits 64 Hz → 22,000 Hz
Mounting Type 1/4 in – 20 Threaded Insert
Available Orientations Vertical
Mounting Location Bottom of Speakers
Available Orientations Vertical
Speaker Inputs (Set) 5-Way Binding Posts – Gold-Plated
Recommended Amplifier Power Per Channel 20 watts → 150 watts
A/V Receiver Crossover Settings Small (80 Hz)
