Description

Specifications
Size & weight
Dimensions
Height: 440mm (17.3 in)
Width: 240mm (9.4 in)
Depth: 373mm (14.7 in)
Net weight
15.55kg (34.3 lb)
Technical details
Technical features
Diamond tweeter
Solid body Tweeter-on-Top
Continuum™ cone bass/mid
Anti-Resonance plug
Matrix™
Flowport
Description
2-way vented-box system
Drive units
1x ø25mm (1in) Diamond dome high-frequency
1x ø165mm (6.5in) Continuum cone bass midrange
Frequency range
34Hz to 35kHz
Frequency response
42Hz to 28kHz (+/-3dB from reference axis)
Sensitivity
88dB (on axis at 2.83Vrms at 1m)
Harmonic distortion
2nd and 3rd harmonics (90dB,1m on axis)
<1% 90Hz – 20kHz <0.3% 120Hz – 20kHz Nominal impedance 8Ω (minimum 4.6Ω) Recommended amplifier power 50W – 120W into 8Ω on unclipped programme Max recommended cable impedance 0.1Ω
