Description
Audiolab 8300 Power Amplifier
The Audiolab 8300XP Stereo Power Amplifier is a classic audiolab power amplifier delivering a solid crisp, clean sound. Styled in audiolabs authentic redefined aesthetics, a true descendant from a range of amplifiers revered throughout the world for their ability to perform at the highest level.
Rate power output
140W RMS (8Ω <1% THD, 1kHZ stereo)
230W RMS (4Ω <1% THD, 1kHZ stereo)
480W RMS (8Ω <1% THD, 1kHZ bridge)
Gain 29dB @ 1kHz (stereo)
36dB @ 1kHz (bridge)
Input sensitivity 1100mV
Input impedance 15k (balanced) 10k (unbalanced)
Frequency response -3dB 20Hz – 80kHz
+/-1dB 20Hz – 30kHz
Total harmonic distortion (THD) 0.004% (20W, ref. 1kHZ)
Intermodulation distortion (IM) 0.004% (20W, ref. 7kHz + 60Hz)
Transient intermodulation distortion (TID) 113dB (A Weighted, ref. 140W)
Signal-to-noise ratio (S/N) 140W / 113dB
Damping factor 160
